Products / Threaded Inserts For PCB / Broaching Nut Inserts For PCB



Deepak Brass Industries Broaching nuts provide a permanently attached strong thread in non-ductile materials such as printed circuit board, polycarbonate, acrylic, glass epoxy and resin laminate components as well as ductile panels.

The Broaching type Nut of Deepak Brass Industries is an Ideal choice when Sheet Metal of Glass Laminate or Epoxy Base are being used. They are a common choice in many Electronic Products and Applications.

Material : Carbon steel (finished in electro tin plating (zinc optional)), 300 series stainless steel (finished per Passivated ASTM A380), Brass Suitable for use in: Materials with Rockwell Hardness of B-60 or less.

Thread : Class 2B, MIL-S-772, (6g ISO metric).

Available thread sizes :

Inches :
  • #2-56
  • #4-40
  • #6-32
  • #8-32
  • #10-24
  • #10-32

Metric :
  • M2 x 0.4
  • M2.5 x 0.45
  • M3 x 0.5
  • M4 x 0.7
  • M5 x 0.8

Broaching fasteners provide strong reusable thread in nonductile material such as printed circuit boards, polycarbonates, acrylics, resins, epoxy etc. Broaching parts can also be installed into aluminum as alternative to self-clinching fasteners.

Applications


Threaded Inserts for Plastics, Threaded Inserts for Thermosetting Plastics, Threaded Inserts for Thermoplastics, Threaded Inserts for Injection Moulding, Threaded Inserts for Sheet Metals. Threaded Inserts for Woods, Timber, Plywood & Laminates, Threaded Inserts for Fibreglass, Threaded Inserts for Epoxy & Rubber, Threaded Inserts for PCBs, Custom Inserts for various Fastening Solutions.

Material :
Our Threaded Inserts are available in Brass, Stainless Steel, Carbon Steel, Aluminium & Silicon Bronze material as per Fastening Applications.
