Products / Threaded Inserts For Plastics / Heat / Ultrasonic Inserts



  • Deepak Brass Industries manufactures Ultrasonic brass inserts designed for ultrasonic or heat installation into thermoplastics and structural foam materials. The external configuration features parallel diagonal knurls for optimum torque resistance and undercuts for superior tensile strength.

  • A flange provides positive pressure to the molten plastic, assuring complete filling of the knurls and undercuts for high assembly strength. The tapered design allows for rapid and accurate positioning of the insert prior to installation. Two lengths to choose from for increased design flexibility.

    • Ultrasonic Inserts or Heat Inserts are classified as

    • Ultrasonic Inserts with Head
    • Ultrasonic Locking Style Inserts
    • Ultrasonic Locking Style Inserts with Head
    • Ultrasonic Double End Inserts
    • Ultrasonic Tapered Inserts
    • Ultrasonic Straight Inserts

        • Diagonal knurls and undercuts provide superior assembly strength. Excellent design for automated systems

        For post moulding into thermoplastic materials these ultrasonic inserts provide strong wear-resistant threads.

        Some thermoplastics, like polycarbonates and structural foams, are brittle – especially in thin-wall applications. Designed for straight holes using ultrasonic or thermal processes, our threaded inserts for plastic add considerable strength. They are our most popular brass inserts, offering the most overall length choices.

        Our Thr eaded inserts feature two opposing bands of sharp diagonal knurls, providing high tensile pull-out load carrying capability. Little or no stress is applied to the walls of the molded holes. A lead-in pilot diameter assures true perpendicular alignment.

        Three Types of Knurling are available Straight, Hexagonal or Cross, Diamond Knurling as per design Criteria.

        Material : Brass, Stainless Steel & Aluminium.

        Available : In a wide variety of thread sizes, stud lengths and options.

    Threaded Inserts

    Send Inquiry

    Applications

    Threaded Inserts for Plastics, Threaded Inserts for Thermosetting Plastics, Threaded Inserts for Thermoplastics, Threaded Inserts for Injection Moulding, Threaded Inserts for Sheet Metals. Threaded Inserts for Woods, Timber, Plywood & Laminates, Threaded Inserts for Fibreglass, Threaded Inserts for Epoxy & Rubber, Threaded Inserts for PCBs, Custom Inserts for various Fastening Solutions.

    Material :
    Our Threaded Inserts are available in Brass, Stainless Steel, Carbon Steel, Aluminium & Silicon Bronze material as per Fastening Applications.
